What factors should I consider when choosing a trowel size for tile installation?

One of the most crucial aspects of tile installation is choosing the right trowel size. Various factors such as the shapes and sizes of the trowels, the types of notches, and the tile size and placement should be considered.

What is the importance of the tile placement in selecting the trowel size?

Tile placement significantly affects the trowel size selection. For instance, if you're laying tiles on the floor, the mortar bed needs to be thicker to withstand foot traffic. Likewise, if the surface you're laying tiles on slopes a bit, you would need to back-butter or spread out your mud-bed slightly thicker.

What is the general guide to the size of trowel based on the tile size and placement?

Here is a general guide to the size of trowel to use based on the tile size and placement: 3/16″ to 1/4″ V-notch: Mosaics tiles up to 4-1/2″ glazed wall tile. 1/4″ x 1/4″ U or Square notch: 4″ to 8″ tile. 1/4″ x 3/8″ U or Square notch: 8″ to 16″ tiles. 1/2″ x 1/2″ U or Square notch: 16″ and larger.

What are the different types of notches, and how do they affect tile installation?

There are three primary types of notches - V-shape, U-shape, and square-notch. V-shape spreads less thinset than the same-sized square-notch, while the U-notch spreads out more than the v-notch but less than the square-notch. The major difference is how the thinset lies, affecting tile adhesion. Choosing the right trowel size is crucial for successful tile installation. The trowel size should match the tile size, and the type of notch you use will affect the concentration level of thinset. Also, consider the placement of the tiles and the surface you'll be laying them on to determine the appropriate trowel size.

What should I keep in mind for a successful tile installation?

To really understand which trowel type to use, and how to properly use it, watch the video provided. Keep in mind that choosing the right trowel size is crucial for a successful tile installation. The trowel size should match the tile size, and the type of notch you use will affect the concentration level of thinset. Also, consider the placement of the tiles and the surface you'll be laying them on to determine the appropriate trowel size.

ARDEX LIQUID BACKERBOARD®- 48 Piece Pallet

Name: ARDEX LIQUID BACKERBOARD®- 48 Piece Pallet
Brand: Ardex
SKU: 12438P
Price: 3143.4 USD
Availability: InStock

SKU 12438P

by Ardex

$3,143.40 - $3,143.40

$3,143.40

$3,143.40 - $3,143.40

$3,143.40

Achieve Faster, Easier Tile Prep with ARDEX Liquid Backerboard

ARDEX Liquid Backerboard self-levels in a single pour up to 1-1/4", replacing traditional backerboard installation over wood and concrete subfloors.

The seamless underlayment levels floors fast without lath reinforcement, allowing tile installation in as little as 6 hours.

Key Features:

Self-levels without lath reinforcement up to 1-1/4"
Walkable in 2-3 hours, tile in 6 hours
Replaces traditional backerboard installation
Smooth and level wood and concrete floors
Excellent 65 sq. ft. coverage at 1/8" thickness
Encapsulate in-floor heating systems

With faster installation and drying times, Liquid Backerboard boosts productivity for pros prepping subfloors for flawless tile and stone jobs.

Speed up project timelines with ARDEX Liquid Backerboard Self-Leveling Underlayment.

Standards

SystemOne
Tested in Accordance with ASTM C1708

Installation

Mixing Ratio:

6 quarts (5.7 L) of water per 50 lb. (22.7 kg) Bag

Coverage:

32.5 sq. ft. per bag at 1/4” (3 sq. m at 6 mm)

65 sq. ft. per bag at 1/8’’ (6 sq. m at 3 mm)

*Coverage will vary depending on the texture of the surface being smoothed.

Performance

Flow Time: 10 minutes
Compressive Strength (ASTM C109/mod – Air cure only): 3,000 psi (210 kg/sq. cm) at 28 days
ASTM C627 Rating (Robinson-Type Floor Tester): Classified as extra heavy
Flexural Strength (ASTM C348): 700 psi (49 kg/sq. cm) at 28 days
Walkable: 2 – 3 hours
Install Flooring and Waterproofing: See Installation of Flooring and Waterproofing section in Technical Data
VOC: 0
Packaging: 50 lb. (22.7 kg) bag
Storage: Store in a cool, dry area. Do not leave bags exposed to sun.
Shelf Life: 1 year, if unopened
Warranty: ARDEX L.P. Standard Limited Warranty applies

ARDEX LIQUID BACKERBOARD®- 48 Piece Pallet

Achieve Faster, Easier Tile Prep with ARDEX Liquid Backerboard

Standards

Installation

Performance
